REX-CELL™ L SERIES
Multi-energy X-ray imaging for large objects
Applications
Key features
Specifications
| Item | Description |
|---|---|
| Dimension | 2.6 m Width × 2.6 m Height × 6 m Depth |
| Weight | 2000 – 2500 kg |
| Power input | 220-230 VAC, 10 A, 50/60 Hz (1500 W max power consumption) |
| Detector* recording speed *Other types of detectors available on request | 191 fps at 4×4 binning mode (300 um/pixel) 155 fps at 2×2 binning mode (150 um/pixel) 59 fps without binning (75 um/pixel) |
| Detector size | 1000 mm × 0.8 mm (panel detectors are also available) Other sizes available on request |
| Detector sensor | High efficiency, GADOX, NDT |
| Spatial resolution | Maximum 75 um without binning Minimum 300 um at 4×4 binning |
| Work temperature | Indoor room temperature |
| Max humidity | 80% (no condensation) |
| Control system | Security key switch, push button and software activation |
| Heating and cooling | Heating: Electric heater Cooling: Air cooled |
| Software | FlowDIARY™ 4.0 |
| PC specs | Dell workstation T5810: Intel i7, 32 GB RAM, 500G SSD, 4TB HDD, WIN 7/10 64bits |
| Storage Temperature | -10 – +50 C |
| Storage humidity | 10 – 90% (no condensation) |
| Health, safety and environment | Conform with all the regulations for the use of industrial X-ray systems and is approved by European and local authorities |
| Training and support | All training on calibration, operation and data analysis is included 12-month technical support after delivery are included (unlimited hours) |
| Maintenance | One major maintenance within the first 12 months is included |
| Warranty | 1 year after delivery |
